該設備已投放多個城市。是大中院校、科研院所 、企業實驗室 、奶吧的產品小試或中試專用設備 。用于奶粉、洗衣粉等產品的生產工藝。
1、自動進料-消毒-剪切化料-調配-滅菌-真空濃縮-噴霧干燥-灌裝-CIP清洗-灌裝全自動一鍵式操作。
2、采用進口電腦程序控制系統和電器配件，觸摸屏人機界面
3、巴氏滅菌功能●剪切化料及調配功能●管道消毒功能●CIP自動清洗功能●真空濃縮功能●噴霧干燥功能●具有二次熱回收功能、熱利用率高
4、采用液態相變技術，確保產品無結垢、掛壁、褐變、焦糊等質量問題;
具有自動控溫調節、上下限報警、溫度在線跟蹤、10位溫度檢測曲線圖象顯示、自動控制運行與監控功能，便于教學。
5、該設備工藝流程和產品工藝流程與工廠接近，技術路線及工藝控制參數與工廠參數相同
The equipment is my company's first domestic product, has been put a number of cities. Is a large and medium-sized institutions, research institutes, enterprise laboratories, milk bar products, small test or pilot special equipment. For milk powder, detergent and other products of the production process.
1, automatic feeding - disinfection - shear material - deployment - sterilization - vacuum concentration - spray drying - filling - CCI cleaning - filling automatic one - button operation.
2, the use of imported computer program control system and electrical accessories, touch screen man-machine interface
3, pasteurization function●shear material and deployment of the function●pipeline disinfection●CIP automatic cleaning function●vacuum enrichment function●spray drying function●with a secondary heat recovery function, high heat utilization
4, the use of liquid phase change technology to ensure that products without scaling, wall, browning, coke and other quality problems; With automatic temperature control, upper and lower limit alarm, temperature online tracking, 10-bit temperature detection curve image display, automatic control operation and monitoring functions, easy to teach
5, the equipment process and product process and factory close to the technical route and process control parameters and factory parameters the same
|
